Free Cisco 300-710 Practice Exam with Questions & Answers | Set: 12

In a passive IPS deployment for a Cisco Secure Firewall Threat Defense (FTD) device, the administrator must configure the interface to operate in passive mode. This involves setting the interface mode, associating it with a security zone, enabling the interface, and setting the MTU parameter.

Steps:

Set the interface mode to passive:

In FMC, navigate toDevices > Device Management.

Select the FTD device and configure the relevant interface.

Set the interface mode to "Passive."

Associate the interface with a security zone:

Create or select an appropriate security zone.

Assign the passive interface to this security zone.

Enable the interface:

Ensure the interface is enabled to receive traffic.

Set the MTU parameter:

Configure the Maximum Transmission Unit (MTU) parameter as required.

This ensures that the FTD device can inspect traffic passively without impacting the network flow.

Integrated routing and bridging (IRB) is a feature that allows you to route between different bridge groups on a Cisco FTD device. A bridge group is a logical interface that acts as a container for one or more physical or logical interfaces that belong to the same layer 2 broadcast domain. You can assign an IP address to a bridge group interface (BVI) and enable routing protocols on it, just like a regular routed interface. However, when you run a dynamic routing protocol on a Cisco FTD device in IRB mode, you can only use nonbridge interfaces as routing peers. You cannot use bridge group interfaces or bridge group member interfaces as routing peers2. This is because the routing protocol packets are sent and received on the nonbridge interfaces, and the bridge group interfaces are used only for forwarding data traffic3.

Reference”https://www.cisco.com/c/en/us/td/docs/security/firepower/620/configuration/guide/fpmc-config-guide-v62/working_with_intrusion_events.html
