Free Cisco 300-430 Practice Exam with Questions & Answers | Set: 2

The primary change to the network when adding APs for location-based services, such as VolMLAN, would be the AP footprint. This refers to the physical coverage area of the access points. Increasing the AP footprint enhances the ability to perform location-based services by improving the accuracy of triangulation and location tracking of devices. This is because a denser AP footprint allows for more precise determination of a device’s location within the network. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide, specifically the sections discussing location-based services and AP deployment strategies for optimal coverage and location tracking.

To load balance the data coming through NMSP from the WLCs and spread the load between multiple CMX servers, the configuration cmxctl config feature flags nmsplb.cmx-ap-grouping true should be used. This enables the load balancing feature and helps optimize the data flow for APs in a large network environment. References: The configuration for load balancing in CMX is explained in the certification guide, which outlines the commands and flags necessary to manage data flow efficiently.

To rename access points and add them to the correct AP groups on a wireless controller, the minimum custom attributes required using Cisco ISE TACACS is role1=WIRELESS. This role provides the necessary permissions for read/write access to wireless-related configurations. References := (CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide)

 Configuring an AVC profile for the Jabber traffic and applying it to the WLAN ensures that voice traffic from Cisco Jabber receives Platinum QoS while keeping other WLAN traffic at Silver class. AVC allows for deep packet inspection which can identify Jabber application packets so they can be given priority over other types of traffic.

When performing a Cisco Hyperlocation accuracy test, the relevant parameters include the X, Y real location and the client MAC address. The X, Y coordinates provide the actual location data needed for the test, while the client MAC address identifies the specific device being located.

The angle of arrival (AoA) method for client tracking determines the location of a wireless device using triangulation. This technique involves measuring the angle at which the signal arrives at different receivers (access points) and using this information to pinpoint the device’s location within the network. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

To ensure that all Android devices are placed into a separate VLAN on their wireless network without deploying ISE, the feature that must be implemented on the Cisco WLC is “WLAN local policy”. This feature allows the network administrator to create policies that can classify and segregate devices based on their operating system, in this case, Android devices, into a designated VLAN. References := (CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide)

To address concerns about detecting spurious threats from channels not used by the wireless infrastructure, deploying APs in monitor mode (B) and local mode with WIPS submode (D) would be beneficial. Monitor mode allows APs to listen to the wireless spectrum and identify potential threats, while WIPS (Wireless Intrusion Prevention System) submode enhances the ability to detect and mitigate wireless threats. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

To route wireless traffic from the branch through the firewall at corporate headquarters, the correct Cisco FlexConnect configuration is central authentication and central switching. This setup ensures that both user authentication and data traffic are handled centrally at the corporate headquarters, allowing the firewall to inspect and route the traffic accordingly. Local RADIUS servers in each branch can still be used for redundancy or other purposes, but the central control of traffic is maintained. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide.

Local EAP (Extensible Authentication Protocol) allows wireless LAN controllers to directly authenticate clients using an internal database, which can be useful when external RADIUS servers are unreachable. By enabling local EAP, client devices can still connect to wireless networks even if communication with RADIUS servers fails, ensuring continuous network access for users. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide
