Free Cisco 300-425 Practice Exam with Questions & Answers

When identifying network requirements, it’s important to consider the number of wireless devices that will need access to ensure sufficient capacity and coverage. The business type can influence the types of applications and services that will be used, which in turn affects the network design.

Guest anchoring requires mobility tunnels to be established between the foreign and anchor WLCs. For these tunnels to function, the firewall must allow specific ports for communication. UDP port 16666 is the port used for mobility traffic in Cisco wireless networks, and if it is not allowed through the firewall, MPING and mobility tunnels will fail. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice

 In a high-availability configuration, orphaned APs will join the controller with the lowest percentage of associated Access Points (APs) per license capacity by default. This ensures a balanced distribution of APs across the controllers in the mobility group, optimizing resource utilization and network performance. References: Designing Cisco Enterprise Wireless Networks (ENWLSD 300-425)

 LAG-based redundancy is chosen for its ability to provide continuous connectivity as long as one port in the LAG is operational (B), utilize the full bandwidth capacity of all the links in the LAG (E), and allow for the grouping of ports into multiple LAGs for increased redundancy and bandwidth (F). References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide.

 Cisco FlexConnect mode is designed for branch offices that lack a wired backhaul. It allows APs to switch client data traffic locally while still performing client authentication centrally. This mode provides the flexibility needed for branch deployments, ensuring that client traffic is handled efficiently even if the WAN link to the central site is down. References: Cisco FlexConnect technical documentation and Designing Cisco Enterprise Wireless Networks (ENWLSD) training.

The 5 GHz band is recommended for voice over wireless due to its wider channel bandwidths, allowing for higher data rates. Setting the cell boundary at -67 dBm ensures sufficient signal strength for reliable voice communication. References: CCNP Enterprise Wireless Design ENWLSD 300-425 Official Cert Guide.

For accurate location services, it is recommended that each location-ready AP hears at least four other APs at a signal level of -75 dBm or better. This ensures sufficient signal overlap and triangulation accuracy for reliable client location tracking. References: Cisco’s guidelines on wireless network design for location services.

 In a high-density environment where 5 GHz coverage is provided by nine APs, disabling the 2.4 GHz radios on some APs can reduce co-channel interference because the 2.4 GHz band has fewer non-overlapping channels. This approach helps maintain coverage while mitigating interference.

 Before replacing old APs with IEEE 802.11ac-capable APs, it is crucial to check the software version of the wireless LAN controller. The controller’s firmware must support the newer standards and capabilities of 802.11ac APs. An outdated software version may not support the advanced features and performance enhancements offered by 802.11ac technology, leading to compatibility issues and suboptimal network performance.

References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice.

 The Cisco 5520 WLC v8.3 requires a base license to use OfficeExtend AP functionality, which allows remote workers to have the same wireless connectivity as they would in an office environment.
