Free USGBC LEED-AP-BD+C Practice Exam with Questions & Answers | Set: 3

ASHRAE 62.1-2010 is the standard that an engineer should use when establishing minimum ventilation rates for a new mechanically ventilated space to earn Indoor Environmental Quality, Minimum Indoor Air Quality Performance. This is the standard referenced by the LEED V5 BD+C Reference Guide for this prerequisite. Local building code, International Mechanical Code 2012, and the ventilation code requiring the greatest volume of outside air are not acceptable alternatives for this prerequisite.

The Indoor Environmental Quality Credit, Interior Lighting, requires the project team to provide individual occupant lighting control for at least 90% of the individual occupant spaces, or at least 50% of the shared multi-occupant spaces. The lighting control must enable occupants to adjust the lighting to suit their individual tasks and preferences, and must have at least three lighting levels, excluding off1. Therefore, a three level (on, 25%, off) lighting control meets the requirements of this credit, while a two level (on, off) lighting control does not. A three level (on, 50%, off) or a three level (on, 75%, off) lighting control may also meet the requirements, depending on the lighting power density and the daylight availability in the space2.

Quality views are defined in LEED as those which consist of multiple elements of nature, weather, or movement that allow for a connection beyond the interior space. Views that allow a clear line of sight to the exterior via vision glazing, with a view factor of 3 or greater, qualify for this credit. Fixed glazing in common spaces can also contribute to this credit.

The combined strategies produce a 35% reduction in potable-water consumption: 25% from efficiency measures plus another 10% from harvested rainwater. Under the WEc2 Whole-Project Water Use approach, that level of reduction reaches the four-point performance tier represented by Option C. The whole-project method evaluates applicable water end uses collectively rather than treating plumbing fixtures, irrigation, process water, and alternative supplies as unrelated measures. Rainwater used for suitable nonpotable applications reduces demand on municipally supplied potable water and therefore contributes to the calculated reduction when properly included in the project water balance. The project must document baseline demand, proposed demand, end-use assumptions, alternative-water availability, storage, treatment, and intended uses to demonstrate the claimed reduction and earn the corresponding points.

================

According to the LEED V5 Reference Guide for Building Design and Construction, Option 2 of the Sourcing of Raw Materials credit requires using products that meet at least one of the responsible extraction criteria for at least 25%, by cost, of the total value of permanently installed building products in the project 1 . Therefore, for a project with a material cost of $100,000, the minimum material value needed to achieve this option is 25% of $100,000, which is $25,000.

Option 1 of the Innovation credit under LEED V5 .1 BD+C rating system (Building Design and Construction) allows for achieving significant, measurable environmental performance using a strategy not addressed in the LEED green building rating system 1 . Implementing an employee engagement and education plan could be a unique strategy that promotes sustainability and environmental stewardship, which is not specifically addressed in the LEED rating system.

Light Emitting Diode (LED) is an energy efficient lamp type that is free from mercury. Mercury is a toxic metal that can pose health and environmental risks when released from broken or discarded lamps. LED lamps do not contain mercury or other hazardous substances, and they also have longer lifespans and lower energy consumption than other lamp types 1 2 . References : No mercury Lights | LEEDuser ; LED Lighting

According to the LEED V5 : Building Design + Construction Guide, the Location and Transportation Credit, Access to Quality Transit has two options: Option 1. Transit-Served Location and Option 2. Transit Service Quality. Option 1 can earn 1 to 4 points depending on the percentage of functional entries within walking distance of transit stops or stations. Option 2 can earn 1 point if the project meets the minimum weekday and weekend headways for bus, streetcar, or informal transit stops, or rail stations or ferry terminals. The maximum number of points a project can achieve under this credit is 4 points by meeting both options 1 . References : LEED V5 : Building Design + Construction Guide, Location and Transportation Credit, Access to Quality Transit, Requirements 1

Selecting a high-reflectance interior paint that meets the SCAQMD Rule 1113 can help contribute towards two credits: Indoor Environmental Quality Credit, Low-Emitting Materials and Indoor Environmental Quality Credit, Interior Lighting. The first credit requires that interior paints and coatings comply with the VOC content limits specified by the SCAQMD Rule 1113 or equivalent standards to reduce indoor air contaminants that are odorous, irritating, and/or harmful to the comfort and well-being of installers and occupants 1 The second credit aims to provide high-quality lighting that supports visual acuity and occupant comfort, and that responds to the needs of the space and its users. One of the strategies to achieve this credit is to use light-colored finishes with a minimum reflectance of 0.7 for ceilings, 0.5 for walls, and 0.2 for floors to increase the effectiveness of daylighting and electric lighting systems 2 References : 1 : LEED V5 Reference Guide for Building Design and Construction, Indoor Environmental Quality Credit: Low-Emitting Materials, page 692. 2 : LEED V5 Reference Guide for Building Design and Construction, Indoor Environmental Quality Credit: Interior Lighting, page 715.

The correct answer is C, the Cx agent for the project must conduct or oversee the Cx of the PV system. According to the LEED V5 Reference Guide for Building Design and Construction, the Energy and Atmosphere Prerequisite, Fundamental Commissioning and Verification, requires that all energy-related systems, including renewable energy systems such as PV, be commissioned by an independent commissioning agent (CxA) or a qualified member of the project team who reports to the owner. The CxA or the qualified team member must perform or oversee all commissioning activities, including developing a commissioning plan, reviewing design documents and submittals, verifying installation and performance, and preparing a commissioning report 1 2 References : 1 : LEED V5 Reference Guide for Building Design and Construction, Energy and Atmosphere Prerequisite: Fundamental Commissioning and Verification, page 562. 2 : LEED V5 Reference Guide for Building Design and Construction, Glossary, page 1020.
