To run a container on SRV1 using the mcr.microsoft.com/windows/servercore/iis image, publish port 60 on the container to port 5001 on SRV1, and ensure it runs in the background, you can follow these steps:

Step 1: Pull the IIS Image First, pull the IIS image from the Microsoft Container Registry:

docker pull mcr.microsoft.com/windows/servercore/iis

Step 2: Run the Container Next, run the container with the required port mapping and ensure it runs in the background using the -d flag:

docker run -d -p 5001:60 --name iis_container mcr.microsoft.com/windows/servercore/iis

This command will start a container named iis_container using the IIS image, map port 60 inside the container to port 5001 on SRV1, and run the container in detached mode.

Step 3: Verify the Container is Running To verify that the container is running and the port is published, use the following command:

docker ps

This will list all running containers and show the port mappings.

Step 4: Access the IIS Server You can now access the IIS server running in the container by navigating to http:// :5001 in a web browser, where is the IP address of SRV1.

Note: Ensure that Docker is installed on SRV1 and that the port 5001 is open on the firewall to allow incoming connections1.

By following these steps, you should be able to run the IIS container on SRV1 with the specified port mapping and have it running in the background.

To map \\dd.contoso.com\instal1 as drive H for all users using Group Policy Preferences and ensure that the new drive mapping takes precedence over any existing mappings, follow these steps:

Step 1: Open Group Policy Management Console Open the Group Policy Management Console (GPMC) on a machine that has administrative privileges over the domain.

Step 2: Create or Edit a GPO Create a new Group Policy Object (GPO) or edit an existing one that applies to the users who need the drive mapping.

Step 3: Navigate to Drive Mappings In the GPO Editor, navigate to:

User Configuration -> Preferences -> Windows Settings -> Drive Maps

Step 4: New Drive Mapping Right-click on Drive Maps and select New -> Mapped Drive.

Step 5: Configure Drive Mapping In the New Drive Properties window, configure the following settings:

Action: Select Replace. This action will overwrite any existing mappings with the same drive letter.

Location: Enter the UNC path \\dd.contoso.com\instal1.

Drive Letter: Choose H: from the drop-down menu.

Reconnect: Check this option if you want the drive mapping to persist across logon sessions.

Label As: Optionally, provide a label for the drive mapping.

Hide/Show this drive: Set according to your preference.

Hide/Show all drives: Set according to your preference.

Step 6: Common Tab Go to the Common tab and configure the following:

Run in logged-on user’s security context (user policy option): Check this option.

Item-level targeting: Click on Targeting and set up any specific criteria if needed.

Step 7: Apply the GPO Click Apply and then OK to save the drive mapping configuration.

Step 8: Link the GPO Link the GPO to an Organizational Unit (OU) or domain that contains the users who should receive the drive mapping.

Step 9: Update Group Policy Instruct users to log off and log back on, or use the gpupdate /force command to refresh Group Policy on their computers.

One possible solution to register SRV1 to sync Azure file shares using the 34646045 Storage Sync Service is to use the Register-AzStorageSyncServer cmdlet from the Az.StorageSync module. This cmdlet establishes a trust relationship between the server and the Storage Sync Service, which is required for creating server endpoints and syncing files. Here are the steps to register SRV1 using the cmdlet:

On SRV1, open PowerShell as an administrator and run the following command to install the Az.StorageSync module if it is not already installed:

Install-Module -Name Az.StorageSync

Run the following command to import the Az.StorageSync module:

Import-Module -Name Az.StorageSync

Run the following command to sign in to your Azure account and select the subscription that contains the 34646045 Storage Sync Service:

Connect-AzAccount

Select-AzSubscription -SubscriptionId

Run the following command to register SRV1 with the 34646045 Storage Sync Service. You need to specify the resource group name and the Storage Sync Service name as parameters:

Register-AzStorageSyncServer -ResourceGroupName -StorageSyncServiceName 34646045

Wait for the registration to complete. You can verify the registration status by checking the Registered servers tab on the Azure portal or by running the following command:

Get-AzStorageSyncServer -ResourceGroupName -StorageSyncServiceName 34646045

Now, SRV1 is registered with the 34646045 Storage Sync Service and ready to sync Azure file shares. You can create server endpoints on SRV1 and cloud endpoints on the Azure file shares to define the sync topology.

TASK 5

???? Objective:

Configure a Group Policy Preference to create a shortcut to \\srvi.contoso.com\data on the desktop of users in the Server Admins OU.

Step-by-Step Guide: Using Group Policy Preferences to Create a Desktop Shortcut

✅ Step 1: Open Group Policy Management Console (GPMC)

Log in to a DC or a management computer with RSAT installed.

Open Group Policy Management (gpmc.msc).

✅ Step 2: Create a New GPO

In the GPMC console, expand the forest and the domain (e.g., contoso.com).

Right-click the OU named Server Admins and select Create a GPO in this domain, and Link it here.

Name the GPO, e.g., Desktop Shortcut for Server Admins.

✅ Step 3: Edit the GPO

Right-click the newly created GPO and select Edit.

This opens the Group Policy Management Editor.

✅ Step 4: Navigate to User Preferences

In the editor, expand:

User Configuration > Preferences > Windows Settings > Shortcuts.

✅ Step 5: Create the Shortcut

Right-click Shortcuts and select New > Shortcut.

In the New Shortcut Properties window:

Action: Create

Name: Data Folder

Target Type: File System Object

Location: Desktop

Target Path: \\srvi.contoso.com\data

Optionally, set an icon or description if you want.

✅ Step 6: Configure Item-Level Targeting (Optional)

If you want to limit this shortcut strictly to specific users/groups, click the Common tab.

Check Item-level targeting and configure conditions (optional).

For this scenario, linking the GPO to the Server Admins OU is usually sufficient.

✅ Step 7: Close and Update

Close the editor.

In GPMC, ensure the GPO is linked to the Server Admins OU.

Force a Group Policy Update on client computers:

On a client computer:

gpupdate /force

Or wait for the next Group Policy refresh cycle.

✅ Step 8: Verify

Log in as a user in the Server Admins OU.

The shortcut to \\srvi.contoso.com\data should appear on the desktop.

Storage tiering requires both standard HDDs and SSDs. We cannot use Pool1 because it does not have any SSDs.
