Free Cisco 350-701 Practice Exam with Questions & Answers | Set: 10

Data is sent out to the attacker during a DNS tunneling attack as part of the domain name. DNS tunneling is a technique that encodes the data of other protocols or programs in DNS queries and responses. The attacker registers a domain, such as badsite.com, and points it to a server under their control, where a tunneling program is installed. The attacker infects a device with malware, which sends DNS queries to the attacker’s server, using subdomains of badsite.com to encode the data. For example, the malware could send a query for 1234.badsite.com, where 1234 is the encoded data. The attacker’s server decodes the data from the subdomain and sends back a DNS response, which may also contain encoded data in the answer section12. The other options are not correct, because they do not use the domain name to encode the data. The UDP/53 and TCP/53 packet payload and header are used to transport the DNS query and response, but they are not modified by the tunneling technique. The DNS response packet contains the answer to the query, but it is not the only way to send data to the attacker3. References:

1: DNS Tunneling attack - What is it, and how to protect ourselves?

2: What Is DNS Tunneling? - Palo Alto Networks

3: What Are DNS Attacks? - Palo Alto Networks

The Python script in the exhibit uses the Cisco AMP for Endpoints API to get information about the computers in the deployment. It imports the requests library, which allows it to make HTTP requests. It then defines three variables: client_id, api_key, and url. These are used to authenticate and access the API endpoint. The url is set to ‘1’, which returns a list of computers in JSON format. The script then makes a GET request using the requests.get() method, passing the url and the authentication details as parameters. The response from the API is stored in the response variable, and converted to JSON using the response.json() method. The script then loops over each computer in the ‘data’ field of the JSON response, using a for loop. Inside the loop, it extracts the hostname of each computer using the ‘hostname’ key, and prints it using the print() function. Therefore, the script will pull all computer hostnames and print them, which is option C. References:

Overview of the Cisco AMP for Endpoints API

Secure Endpoint API - Cisco DevNet

Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0

Configure a Crypto ISAKMP Key

In order to configure a preshared authentication key, enter the crypto isakmp key command in global configuration mode:

crypto isakmp key cisco123 address 172.16.1.1

https://community.cisco.com/t5/vpn/isakmp-with-0-0-0-0-dmvpn/td-p/4312380

It is a bad practice but it is valid. 172.16.0.0/16 the full range will be accepted as possible PEER

https://www.examtopics.com/discussions/cisco/view/46191-exam-350-701-topic-1-question-71-discussion/#:~:text=Command%20reference%20is%20not%20decisive,172.16.1.128%20cisco123%0ACSR%2D1(config)%23

Testing without a netmask shows that command interpretation has a preference for /16 and /24. CSR-1(config)#crypto isakmp key cisco123 address 172.16.0.0

CSR-1(config)#do show crypto isakmp key | i cisco

default 172.16.0.0 [255.255.0.0] cisco123

CSR-1(config)#no crypto isakmp key cisco123 address 172.16.0.0

CSR-1(config)#crypto isakmp key cisco123 address 172.16.1.0

CSR-1(config)#do show crypto isakmp key | i cisco

default 172.16.1.0 [255.255.255.0] cisco123

CSR-1(config)#no crypto isakmp key cisco123 address 172.16.1.0

CSR-1(config)#crypto isakmp key cisco123 address 172.16.1.128

CSR-1(config)#do show crypto isakmp key | i cisco default 172.16.1.128 cisco123

CSR-1(config)#

A serverless application is one that does not require the developer to manage the underlying infrastructure or servers. Instead, the application code is executed by a cloud provider in response to events or triggers, such as HTTP requests, database changes, or messages. The cloud provider automatically provisions, scales, and manages the resources needed to run the code, and charges only for the time and resources consumed by the execution. A serverless application runs from an ephemeral, event-triggered, and stateless container that is fully managed by a cloud provider. This means that the container is created on demand when an event occurs, and is destroyed when the execution is completed. The container does not store any persistent state or data, and is isolated from other containers. The cloud provider handles the load balancing, fault tolerance, security, and monitoring of the container. A serverless application can leverage various cloud services, such as databases, storage, messaging, analytics, and machine learning, to perform complex tasks and functionalities. Serverless computing is a cloud-native development model that enables developers to focus on the business logic and deliver faster and more scalable applications. References:

Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0, Module 8: Cloud and Virtual Network Security, Lesson 8.1: Cloud Computing Concepts

What is serverless? - Red Hat

Serverless computing and applications | Microsoft Azure

 Transparent mode is a Cisco ASA deployment model that allows the ASA to act as a bump in the wire, or a stealth firewall. In this mode, the ASA does not have an IP address on the network, and it does not participate in routing. Instead, it filters traffic between hosts in the same IP subnet using higher-level protocols such as TCP, UDP, and ICMP. Transparent mode is useful when you want to apply security policies without readdressing the network or changing the default gateway of the hosts. Some of the benefits of transparent mode are:

It preserves the original source and destination IP addresses of the packets, which can be useful for logging and auditing purposes.

It simplifies the configuration of the ASA, as you do not need to configure routing protocols, NAT, or DHCP.

It allows the ASA to inspect non-IP traffic, such as ARP, STP, and CDP.

It supports multiple contexts, which can provide logical separation of traffic for different tenants or customers.

Some of the limitations of transparent mode are:

It does not support VPN, dynamic routing, multicast routing, or QoS.

It requires the use of EtherType ACLs to filter non-IP traffic, which can be complex and cumbersome.

It requires the use of bridge groups and bridge domains to define the interfaces and VLANs that belong to the same broadcast domain.

It requires the use of MAC address learning and aging to maintain a MAC address table for each bridge group.

References :=

Some possible references are:

Cisco ASA Series Firewall CLI Configuration Guide, 9.10 - Transparent Firewall Mode

Deploying ASA - Cisco

Cisco ASA 5500-X Series Firewalls - Configuration Guides - Cisco

 The product that allows Cisco FMC to push security intelligence observable to its sensors from other products is Threat Intelligence Director (TID). TID is a feature of Cisco FMC that enables you to integrate third-party threat intelligence feeds into your security policies. TID collects, aggregates, and correlates observables from multiple sources, such as Cisco Talos Intelligence, Cisco Umbrella, and other external providers. TID then pushes the observables to the sensors that are managed by FMC, such as Firepower Threat Defense (FTD) devices, Firepower appliances, and Cisco Secure Firewall Cloud Native. The sensors can then use the observables to block or monitor traffic based on the reputation and threat level of the IP addresses, URLs, and domains12.

 1: Firepower Management Center Configuration Guide, Version 6.6 - Threat Intelligence Director [Cisco Secure Firewall Management Center] - Cisco 2: Cisco Firepower Threat Defense Configuration Guide for Firepower Device Manager, Version 6.6 - Threat Intelligence Director [Cisco Firepower NGFW] - Cisco

 SNMPv3 is a security model that uses authentication and encryption to provide secure access to devices. SNMPv3 requires the configuration of SNMP groups, users, and views. SNMP groups define the security model, security level, and access rights for a set of users. SNMP users are members of SNMP groups and have passwords for authentication and encryption. SNMP views define the subset of the MIB tree that a group of users can access. To facilitate access to the SNMP views, the network administrator must map the SNMPv3 users to the SNMP views using the snmp-server group command with the v3 and view keywords. This command assigns a view to a group of users and specifies the security model and level for that group. For example, the following command maps the SNMPv3 users in the group admin to the view all using the authPriv security level:

snmp-server group admin v3 authPriv read all write all

This command allows the users in the group admin to access all the MIB objects in the view all using authentication and encryption. The other options are not correct because they are not related to the SNMP views. Option B is incorrect because the password for SNMPv3 authentication is configured for each user using the snmp-server user command with the auth keyword. Option C is incorrect because the encryption algorithm for SNMPv3 is also configured for each user using the snmp-server user command with the priv keyword. Option D is incorrect because the UDP port used by SNMP is not configurable and is always 161 for queries and 162 for traps. References :=

Some possible references for this question are:

SNMP Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3850 Switches) - SNMP Version 3

Configuration Template for SNMPv3 - Cisco Community

Configure ESXi for SNMP v3 - VMware Docs

How to Configure SNMPv3 and How It Works - CBT Nuggets

The Python script code snippet for the Cisco ASA REST API is used to add a global rule into policies. The script uses the urllib2 module to create an HTTP request with the URL, headers, and post_data. The post_data is a JSON object that contains the parameters for the global rule, such as the destination service, the source address, the permit value, and the position. The script also uses the base64 module to encode the username and password for authentication. The script then sends the request to the ASA REST API and prints the status code and the response. If the status code is 201, it means the operation was successful and the global rule was added. If the status code is not 201, it means there was an error and the script prints the JSON error message. The script also handles any HTTP errors and value errors that might occur during the execution. References:

Cisco ASA REST API Quick Start Guide

Configure Secure Access to Use REST API with Python

GitHub - timwukp/Cisco-ASA-REST-API

A Trojan malware attack is a type of malicious code or software that disguises itself as a legitimate program or file to trick users into executing it. Once executed, the Trojan can perform various harmful actions on the infected system or network, such as stealing data, deleting files, or installing other malware. There are different types of Trojan malware attacks, depending on their purpose and behavior. Two common types are:

Rootkit: A rootkit is a type of Trojan that hides itself and other malware from detection and removal by antivirus software or system tools. A rootkit can modify the operating system or the firmware of the device to gain persistent and privileged access to the system. A rootkit can also intercept and manipulate system calls, network traffic, or user input to conceal its activities or redirect them to malicious servers.

Backdoor: A backdoor is a type of Trojan that creates a secret or unauthorized access point to the infected system or network. A backdoor can allow an attacker to remotely control the system, execute commands, upload or download files, or monitor the system activity. A backdoor can also be used to install other malware or launch further attacks on other systems or networks.

 Cisco Advanced Phishing Protection (AAP) is a solution that adds sophisticated machine learning capabilities to Cisco Email Security to block advanced identity deception attacks for inbound email by assessing its threat posture1. It also uses both global and local telemetry data combined with analytics and modeling to validate the reputation and authenticity of senders2. AAP provides sender authentication and BEC detection capabilities, and uses advanced machine learning techniques, real-time behavior analytics, relationship modeling and telemetry to protect against identity deception–based threats3.

In two ways, the Cisco Advanced Phishing Protection solution protects users:

It prevents use of compromised accounts and social engineering. AAP detects and blocks phishing emails that attempt to impersonate legitimate senders, such as executives, partners, or customers, and trick users into revealing sensitive information or transferring funds. AAP analyzes the sender’s identity, behavior, and relationship with the recipient, and assigns a risk score to the email. If the email is deemed suspicious or malicious, AAP can quarantine it, flag it, or deliver it with a warning4.

It automatically removes malicious emails from users’ inbox. AAP provides retrospective analysis and remediation capabilities, which means that it can identify and remove emails that were initially delivered but later found to be malicious. AAP leverages the Cisco Talos threat intelligence network and the Sensor-based solution to continuously monitor the threat landscape and update the email disposition accordingly. If an email is reclassified as malicious, AAP can automatically delete it from the users’ inbox, or notify the administrator or the user to take action45.

The other options are incorrect because they do not accurately describe the functions of AAP. AAP does not prevent all zero-day attacks coming from the Internet, as it focuses on phishing and identity deception attacks. AAP does not prevent trojan horse malware using sensors, as sensors are used to collect and analyze email data, not to block malware. AAP does not secure all passwords that are shared in video conferences, as it is not related to video conferencing security. Therefore, the correct answer is A and C. References:

Cisco’s Security Innovations to Protect the Endpoint and Email

Cisco Advanced Phishing Protection - Cisco Video Portal

Cisco Advanced Phishing Protection At A Glance - AVANTEC

User Guide for Cisco Advanced Phishing Protection

Cisco Secure Email Threat Defense - Cisco

Integrating the Email Gateway with Cisco Advanced Phishing Protection

 The open standard that creates a framework for sharing threat intelligence in a machine-digestible format is STIX (Structured Threat Information Expression). STIX is a language and serialization format that enables the exchange of cyber threat information across organizations, tools, and platforms. STIX defines a common vocabulary and data model for representing various types of threat intelligence, such as indicators, observables, incidents, campaigns, threat actors, courses of action, and more. STIX also supports the expression of context, relationships, confidence, and handling of the threat information. STIX aims to improve the speed, accuracy, and efficiency of threat detection, analysis, and response.

STIX is often used in conjunction with TAXII (Trusted Automated Exchange of Indicator Information), which is a protocol and transport mechanism that enables the secure and automated communication of STIX data. TAXII defines how to request, send, receive, and store STIX data using standard methods and formats, such as HTTPS, JSON, and XML. TAXII supports various exchange models, such as hub-and-spoke, peer-to-peer, or subscription-based. TAXII enables the interoperability and scalability of threat intelligence sharing among different systems and organizations.
