Free UiPath UiPath-ADPv1 Practice Exam with Questions & Answers | Set: 2

When creating aCoded Automationproject in UiPath Studio, adefault namespace is automatically generatedusing theproject name. This helps organize classes and methods and ensures that the structure aligns with best practices for .NET-based development in UiPath.

The Monitoring pages in UiPath Orchestrator are pages that provide information and statistics about the performance and health of your robots, processes, queues, and jobs. You can access the Monitoring pages from the left menu in Orchestrator, under the Monitoring section.

The Include Subfolders filter in the Monitoring pages is a filter that allows you to select whether the contents of the selected folder’s subfolders are displayed in the Monitoring pages. This filter is available when a modern folder is selected from the Folder drop-down list. A modern folder is a type of folder in Orchestrator that supports dynamic and fine-grained permission management, as well as folder-level isolation of data, processes, and execution.

When the Include Subfolders filter is checked, the Monitoring pages display the data for the selected folder and all its subfolders. For example, if you select a modern folder called Sales and check the Include Subfolders filter, the Monitoring pages will show the data for the Sales folder and all its subfolders, such as Sales-East, Sales-West, Sales-North, and Sales-South. This way, you can get a comprehensive view of the performance and health of your robots, processes, queues, and jobs across multiple subfolders.

When the Include Subfolders filter is unchecked, the Monitoring pages display the data only for the selected folder. For example, if you select a modern folder called Sales and uncheck the Include Subfolders filter, the Monitoring pages will show the data only for the Sales folder, excluding its subfolders. This way, you can get a focused view of the performance and health of your robots, processes, queues, and jobs within a specific folder.

The correct answer is B. It allows you to select whether the contents of the selected folder’s subfolders are displayed. This statement accurately describes the functionality of the Include Subfolders filter in the Monitoring pages when a modern folder is selected.

The other options are not correct statements. Option A is incorrect, because the Include Subfolders filter does not allow you to choose between background and foreground processes for the displayed data. Background and foreground processes are types of processes that run in the background or foreground of the robot machine, respectively. You can filter the displayed data by process type using the Process Type filter in the Monitoring pages. Option C is incorrect, because the Include Subfolders filter does not enable you to sort the displayed data based on job priorities. Job priorities are levels of importance that are assigned to jobs when they are created or triggered, such as High, Normal, or Low. You can sort the displayed data by job priority using the Sort By drop-down list in the Monitoring pages. Option D is incorrect, because the Include Subfolders filter does not allow you to allocate licenses per machine for the displayed data. Licenses are resources that are consumed by robots, processes, or users when they perform certain actions in Orchestrator. You can allocate licenses per machine using the License Allocation page in Orchestrator.

The Show Elements button in the Computer Vision wizard is used to highlight all UI elements that have been identified by the Computer Vision analysis. This helps you to see the UI elements that are available for automation and to select the ones that you want to use in your activities. The Show Elements button is located in the top-right corner of the Computer Vision wizard. When you click it, the UI elements are highlighted with different colors and shapes, depending on their type and category. You can hover over each UI element to see its name and properties. You can also use the Filter Elements button to filter out specific UI elements from being processed by the Computer Vision engine.

In the BDD (Behavioral-Driven Development) template structure, the "Setup" part of a test case supports the Surround with mock feature. This section is used to set up the testing environment, including mock configurations.

LINQ (Language Integrated Query) in UiPath is used for efficient data manipulation. The LINQ query 'listOfintegers.Sum(Function(x) x)' correctly demonstrates how to sum integers in a list, making use of LINQ's straightforward and readable syntax.

The Connector Builder for Integration Service is a feature that enables the user to quickly add custom connectors to the tenant catalog in a no-code environment. The custom connectors can wrap any RESTful API and provide rich and scalable functionality on top of the original API1. The Connector Builder supports the following features:

REST APIs with JSON payload: The Connector Builder can connect to external systems that expose their API documentation as REST-compliant and both accept and return JSON2.

Various authentication types including OAuth 2.0 and API Key: The Connector Builder supports different types of authentication methods for the API calls, such as OAuth 2.0, Basic, Personal Access Token (PAT), API Key, etc3.

Building a connector from an API definition or from scratch: The Connector Builder allows the user to start building a connector from an existing API definition, such as a Swagger file, a Postman collection, or a URL, or from scratch by manually adding the API resources and methods4.

Option C is the correct answer, as it lists the features that the Connector Builder supports as defined in the documentation1. Option A is incorrect, because the Connector Builder does not support SOAP APIs or XML payloads, and it can build a connector from other sources besides a Swagger definition. Option B is incorrect, because the Connector Builder supports other authentication types besides OAuth 2.0 and Basic, and it can build a connector from other sources besides a Postman collection.Option D is incorrect, because the Connector Builder does not support SOAP APIs or XML payloads, and it supports other authentication types besides OAuth 2.0.

After running any REFramework test case, the possible statuses are "PASS" or "FAIL". These indicate whether the test case succeeded or encountered an issue, respectively.

The Extract PDF Page Range activity is used to extract a specific set of pages from a PDF file and save them as a new PDF file1. The activity has the following properties:

•Common

oDisplayName: The display name of the activity1.

•File

oFileName: The path of the PDF file you want to extract a range of pages from. This field supports only strings and String variables1.

oOutputFileName: The name you want to use for the file that is generated from the extracted range of pages. This field supports only strings and String variables1.

oPassword: The password of the PDF file, if necessary. This field supports only strings and String variables1.

•Input

oRange: The range of pages that you want to retrieve. You can specify a single page (e.g. “7”), a range of pages (e.g. “7-12”), or a complex range, (e.g. “2-5, 7, 15-End” or “All”). Only string variables and strings are supported. By default, this field is cleared1.

•Misc

oPrivate: If selected, the values of variables and arguments are no longer logged at Verbose level1.

The statement that correctly describes this activity is B. Range argument accepts complex range values or “All”. This statement is true because the Range property allows you to specify the pages that you want to extract from the PDF file using different formats, such as single pages, ranges, or complex ranges1. You can also use the keyword “All” to extract all the pages from the PDF file1.

The other statements are incorrect because:

•A. Password-protected PDF files cannot be processed with this activity. This statement is false because the activity has a Password property that allows you to enter the password of the PDF file, if necessary1. This enables the activity to process password-protected PDF files1.

•C. OutputFileName argument is optional. This statement is false because the OutputFileName property is required for the activity to work1. This property specifies the name of the file that is generated from the extracted range of pages1. If this property is not provided, the activity will throw an exception1.

•D. PageCount argument outputs the number of extracted pages. This statement is false because the activity does not have a PageCount argument1. The activity does not output the number of extracted pages, but only the new PDF file that contains the extracted pages1.

The UiPath Integration Service supports two types of events: Generic and Predefined. Generic events are customizable, while Predefined events are specific to certain integrations and come with predefined configurations.
