Free Fortinet NSE5_SSE_AD-7.6 Practice Exam with Questions & Answers

According to theFortiSASE 7.6 Architecture GuideandFCP - FortiSASE 24/25 Administratormaterials, the solution is built around three primary use cases that support a hybrid workforce:

Secure Internet Access (SIA):This enables secure web browsing by applying security profiles such asWeb Filter,Anti-Malware, andSSL Inspectionin the SASE cloud. It protects remote users from internet-based threats regardless of their location.

Secure Private Access (SPA):This provides granular, explicit access to private applications hosted in data centers or the cloud. It is achieved throughZTNA (Zero Trust Network Access)for session-based security or throughSD-WAN integrationwhere FortiSASE acts as a spoke to an existing corporate SD-WAN hub.

SaaS Security:FortiSASE utilizesInline-CASBandShadow IT visibilityto monitor and control the use of cloud applications.Data Loss Prevention (DLP)is integrated into these workflows to prevent sensitive corporate data from being uploaded to unauthorized SaaS platforms.

Why other options are incorrect:

Option A:While it mentions SD-WAN and Shadow IT, it misses the core definition of SIA (secure web browsing) which is the primary driver for SASE deployments.

Option B:Remote Browser Isolation (RBI)is typically applied to risky or uncategorized websites, not "all websites," due to the high performance and resource overhead.

Option D:FortiSASE is designed to protect data in motion (via security profiles) as well as data stored in sanctioned cloud apps, not "at rest only".

According to theSD-WAN 7.6 Core Administratorstudy guide and theFortinet Document Library, FortiOS maintains strict referential integrity for SD-WAN objects. An SD-WAN member interface cannot be deleted or removed from the configuration if it is still being "used" or referenced by other features.

Reference Locking: In the FortiOS GUI, the "Delete" button for an SD-WAN member is typically grayed out or an error message appears if the interface is part of an active service or monitoring tool.

Performance SLA Dependency: Performance SLAs (health checks) monitor specific member interfaces. If an interface is a participant in an SLA, it is considered "active" by the system. Therefore, a critical first step in the decommissioning process is toremove the member from all Performance SLA definitions. Once the health check is no longer polling that interface, one major reference lock is released.

Other Dependencies: While firewall policies and SD-WAN rules (service rules) also create references, the question specifies the member is "no longer used to steer traffic," implying it may have already been removed from steering rules. However, Performance SLAs often remain active in the background, making their removal the essential next step to permit the deletion of the member itself.

Why other options are incorrect:

Option A: Moving a member between zones doesn't help you delete it; it just changes its logical grouping. It still remains an active SD-WAN member.

Option B: Disabling the physical interface does not remove the configuration references within the SD-WAN engine. The FortiGate will simply report the member as "Down," but it will still exist in the configuration as a member.

Option D: In modern SD-WAN deployments, static routes usually point to theSD-WAN Zone(like virtual-wan-link) rather than individual physical interfaces. Therefore, you don't typically need to delete the static route to remove a single member from the zone.

According to theFortiSASE 7.6 Administration GuideandDigital Experience Monitoring (DEM)documentation, the feature specifically designed to monitor SaaS application performance and connectivity to PoPs isDigital Experience Monitoring (DEM).

SaaS and Path Visibility: DEM assists administrators in troubleshooting remote user connectivity issues by providing enhanced health check visibility forSaaS applications, endpoint devices, and the network path. It provides real-time insights into application performance and latency issues.

PoP Connectivity: It monitors the digital journey from the end-user device through theSecurity Points of Presence (POPs)to the final application, identifying hops where degraded service (packet loss, delay, or jitter) is detected.

Proactive Management: By establishing thresholds and simulating user activities throughSynthetic Transaction Monitoring (STM), DEM allows IT teams to identify performance problems before they impact the business.

Why other options are incorrect:

Option A: Operations widgets provide general status overviews but do not offer the granular per-hop path analysis or specific SaaS transaction monitoring found in DEM.

Option B: FortiView dashboards provide traffic visibility and session data but are not dedicated performance monitoring tools for end-to-end digital experience.

Option C: Event logs record system occurrences and security events but do not provide real-time performance metrics or health check probes for SaaS applications.

According to theFortiSASE 7.6 Feature Administration Guide, steering bypass destinations (also known as split tunneling) allow administrators to optimize bandwidth by redirecting specific trusted traffic away from the SASE tunnel to the endpoint's local physical interface.

Destination Types (Option C): When creating a bypass destination, administrators can select from four distinct types:Infrastructure(pre-defined apps like Zoom/O365),FQDN(specific domains),Local Application(identifying processes on the laptop), orSubnet(specific IP ranges).

Apply Condition (Option B): The "Apply" condition is a flexible setting that allows the administrator to choose when the bypass is active. It can be applied to endpoints that areOn-net(inside the office),Off-net(remote), orBoth. This ensures that if a user is in the office, they don't use the SASE tunnel for local resources, but if they are home, they might still bypass high-bandwidth sites like YouTube to preserve tunnel capacity.

Why other options are incorrect:

Option A: Subnet is one of four types and is not the only type supporting these conditions.

Option D: The system explicitly supports "Both" to ensure consistency across network transitions.

"If a flow is identified as belonging to a defined application category (such as social media), FortiGate will match it to the corresponding service rule (rule 2) and route it through the specified interface, such as port2. However, if the application is not recognized during the session setup, the system defaults to load balancing the traffic using the available tunnels according to the policy for unclassified traffic, ensuring continuous connectivity while waiting for application classification."

This guarantees both performance and resilience.

According to theSD-WAN 7.6 Core Administratorstudy guide andFortiOS 7.6 Administration Guide, the "implicit rule" is the default rule at the bottom of the SD-WAN rule list (ID 0). It is only evaluated if traffic does not match any manually configured SD-WAN rules.

Policy Route Table Context (Option B): SD-WAN rules are technically a specialized form of policy-based routing. For a packet to match theimplicit rule, it must first pass through the routing hierarchy. If traffic matches the implicit rule, it indicates that it did not match any higher-priority user-defined SD-WAN rules or any specific entries in the manualpolicy route tablethat would have intercepted the traffic earlier.

Session Information (Option E): When you use the CLI to inspect an active session (e.g., diagnose sys session list), the output contains a field for theSD-WAN Service ID. If traffic is steered by a user-defined rule, it displays the ID of that rule (e.g., service_id=1). However, when traffic falls through to theimplicit rule, the session information displaysno SD-WAN service ID(it often shows as 0 or is omitted), because the implicit rule does not function as a "service" in the same way user-defined rules do.

Routing Behavior: The implicit rule follows the standard routing table (RIB/FIB) logic. It uses thepriorityanddistanceof the static routes to determine the path. If multiple paths have the same distance and priority, it uses the algorithm set by v4-ecmp-mode, but this is a function of the routing engine, not the SD-WAN engine itself.

Why other options are incorrect:

Option A: While v4-ecmp-mode (e.g., source-ip-based) is used for ECMP routing, this is part of the general FortiOS routing behavior for equal-cost paths in the FIB, whereas the implicit rule simply "hands over" the decision to that routing table.

Option C: When traffic matches the implicit rule, the session is actually flagged with vwl_id=0 and potentially dirty if a route change occurs, but vwl_default is not the standard flag name used in this specific context in the curriculum.

Option D: This is incorrect because the implicit ruledoes respect weight, distance, and priorityas defined in the static routes within the routing table; it does not distribute traffic "regardless" of these values.

According to theFortiSASE 7.6 Feature Administration Guideand the latest updates to theNSE 5 SASEcurriculum, FortiSASE has introduced native lifecycle management for FortiClient agents to reduce the operational burden on IT teams who previously relied solely on third-party MDM (Mobile Device Management) or GPO (Group Policy Objects) for every update.

TheEndpoint Upgradefeature, found underSystem > Endpoint Upgradein the FortiSASE portal, allows administrators to perform the following:

Centralized Version Control: Administrators can see which versions are currently deployed and which "Recommended" versions are available from FortiGuard.

Scheduled Rollouts: You can choose to upgrade all endpoints or specific endpoint groups at a designated time, ensuring that upgrades do not disrupt business operations.

Status Monitoring: The portal provides a real-time dashboard showing the progress of the upgrade (e.g.,Downloading,Installing,Reboot Pending, orSuccess).

Manual vs. Managed: While MDM is still highly recommended for theinitial onboarding(the first time FortiClient is installed and connected to the SASE cloud), all subsequent upgrades can be handled natively by the FortiSASE portal.

Why other options are incorrect:

Option B: Manual upgrades are inefficient for large-scale deployments (~400 users in this scenario) and are not the intended "feature-rich" solution provided by FortiSASE.

Option C: "Onboarding" refers to the initial setup. Re-onboarding every time a version changes would be redundant and counterproductive.

Option D: While the system canmanagethe upgrade, it is not "auto-upgraded on demand" by the client itself without administrative configuration in the portal. The administrator must still define the target version and schedule.

According to theSD-WAN 7.6 Core Administratorstudy guide and theFortiOS 7.6 Administration Guide, when you are migrating a production FortiGate to use SD-WAN, the most critical step involves reconfiguring how traffic is permitted and routed.

Reference Removal Requirement: Before an interface (such as wan1 or wan2) can be added as anSD-WAN member, it must be "unreferenced" in most parts of the FortiGate configuration. Specifically, if an interface is currently being used in an activeFirewall Policy, the system will prevent you from adding it to the SD-WAN bundle.

Firewall Policy Migration (Option A): In a production environment, you mustreplace the references to the physical interfacesin your firewall policies with the newSD-WAN virtual interface(or an SD-WAN Zone). For example, if your previous policy allowed traffic from internal to wan1, you must update that policy so theOutgoing Interfaceis now SD-WAN. This allows the SD-WAN engine to take over the traffic and apply its steering rules.

Modern Tools: While this used to be a purely manual process, FortiOS 7.x includes anInterface Migration Wizard(found underNetwork > Interfaces). This tool automates the "search and replace" function, moving all existing policy and routing references from the physical port to the SD-WAN object to ensure minimal downtime.

Why other options are incorrect:

Option B: While you do need to update your routing (e.g., creating a static route for 0.0.0.0/0 pointing to the SD-WAN interface), the curriculum specifically emphasizes the replacement of references infirewall policiesas the primary administrative hurdle, as policies are often more numerous and complex than the single static route required for SD-WAN.

Option C: You donotneed to disable the interface. It must be up and configured, just removed from other configuration references so it can be "absorbed" into the SD-WAN bundle.

Option D: SD-WAN is abase featureof FortiOS and doesnot require a separate licenseor a reboot to enable.

According to theFortiSASE 7.6 Administration Guideand theFCP - FortiSASE 24/25 Administratorcurriculum, the Agentless deployment mode—commonly referred to asSecure Web Gateway (SWG)mode—is a vital component of the Secure Internet Access (SIA) framework.

Deployment Mechanism: In an agentless deployment, FortiSASE functions as an explicit web proxy. This is achieved by distributing aPAC (Proxy Auto-Configuration) fileto the user's browser, which instructs the device to send its web traffic to the nearest FortiSASE Point of Presence (PoP).

Target Use Case: This mode is specifically designed forunmanaged endpoints, such as those used bycontractors, partners, or temporary workers, where the organization does not have the authority or capability to install the FortiClient agent.

Security Capabilities: Even without an agent, FortiSASE applies afull security stackto the redirected traffic. This includesWeb Filtering,Anti-Malware,SSL Inspection, andInline-CASBto secure HTTP and HTTPS sessions.

Protocol Limitations: Because it relies on proxy settings, this mode is limited to web protocols (HTTP/HTTPS) and does not inherently secure non-web traffic like ICMP, DNS, or custom TCP/UDP applications unless they are specifically proxied.

Why other options are incorrect:

Option A: While it provides secure browsing, session isolation (RBI) is a specific feature that can be used in either mode; the defining characteristic of the agentless use case is the proxy-based redirection for unmanaged devices.

Option C: A PAC file can only secure web traffic (protocols that support proxying), not non-web traffic protocols.

Option D: Agentless mode is the opposite of requiring FortiClient; ZTNA tags generally require the FortiClient agent to provide the necessary telemetry for tag evaluation.
