Free Huawei H12-821_V1.0 Practice Exam with Questions & Answers | Set: 9

The Link State ID in a Type 3 LSA (Summary LSA) indicates the network or subnet being summarized, not the router ID of an ABR. All other statements accurately describe OSPF functionality, making D the false statement ​.

GRE (Generic Routing Encapsulation) is not a Layer 2 VPN technology. Instead, it is a Layer 3 tunneling protocol used to encapsulate a wide variety of network layer protocols inside point-to-point connections. GRE is commonly used for creating VPN tunnels across IP networks,allowing for the transport of various types of payloads. This misunderstanding about GRE being a Layer 2 technology contradicts its definition and typical application ​.

In SNMP (Simple Network Management Protocol), the MIB (Management Information Base) defines the attributes of a managed device. It acts as a structured database of managed objects, each described by a unique OID (Object Identifier). These objects provide critical information and control interfaces for network management. Other elements like the agent (manages the MIB) and NMS (queries the agent) do not define attributes but interact with the MIB ​.

When two BGP peers negotiate the Hold Time, the shorter value between the two configured Hold Time values is selected. This ensures compatibility and maintains the stability of the BGP session ​.

Edge ports are used in RSTP to bypass the spanning tree calculation for ports connected to end devices. By configuring ports like SWD's GE0/0/2 and SWC's GE0/0/2 as edge ports, they transition directly to the Forwarding state upon activation, ensuring faster convergence. Statement A is incorrect because receiving BPDU invalidates the edge port status ​.

Inasynchronousmode, the local device sends BFD control packets at predefined intervals, and the remote device monitors the receipt of these packets to detect connectivity issues. This is one of the two operating modes in BFD, the other beingdemandmode ​.

Comprehensive and Detailed in-depth Step-by-Step Explanation:

In an Intermediate System to Intermediate System (IS-IS) network, aDesignated Intermediate System (DIS)is elected on broadcast networks to perform the following functions:

Represent the broadcast network as a pseudonode.

Generate and update the Link State Protocol Data Units (LSPs) for the pseudonode.

The DIS is elected based on theDIS priorityvalue, which is configured on IS-IS interfaces. If two routers have the same priority, the router with the higher MAC address becomes the DIS.

Thedefault DIS priorityfor IS-IS interfaces is64, which can be modified depending on the network requirements.

Option A (200):Incorrect. This is not the default value.

Option B (64):Correct. This is the default DIS priority value.

Option C (1):Incorrect. This is not the default value.

Option D (100):Incorrect. This is not the default value.

Comprehensive and Detailed In-Depth Explanation:

Router LSAs (Type 1 LSAs)are generated byevery OSPF routerto describe itsdirectly connected linksand their states.

TheE (External) bitin theOptions fieldof a Type 1 LSA indicates whether the router is acting as anAutonomous System Boundary Router (ASBR).

IfE = 1, it means that the router is anASBR, which means it is redistributing external routes (e.g., BGP, static routes) into OSPF.

IR (Internal Router),ABR (Area Border Router), andDR (Designated Router)do not set theE-bitin their Router LSA unless they are also ASBRs.

????Reference:Huawei HCIA-Datacom Study Guide, OSPF Router Types and LSA Options.

RSTP improves convergence by introducing changes to the BPDU handling mechanism and port roles. However, RSTP does not rely on a fixed timeout of four Hello intervals for negotiation failure. Instead, RSTP uses a more dynamic mechanism to detect topology changes. The other options describe valid RSTP improvements ​.

Comprehensive and Detailed in-depth Step-by-Step Explanation:

To answer this question, we need to understand the roles of OSPF routers:

Area Border Router (ABR):

An ABR is a router that connects multiple OSPF areas. It has at least one interface in the backbone area (Area 0) and one or more interfaces in other OSPF areas.

The ABR performs summarization between areas and propagates routing information between them.

Backup Router (BR):

The term "BR" does not exist in OSPF terminology. Instead, OSPF uses the term "Backup Designated Router (BDR)." The BDR is a backup to the Designated Router (DR) in a specific OSPF broadcast or NBMA (Non-Broadcast Multi-Access) network. The BDR takes over the DR's responsibilities if the DR fails.

Key Clarification:

An ABR is related to the hierarchical structure of OSPF areas and is not tied to the DR/BDR election process.

A router can function as an ABR without ever being a DR or BDR, as these are separate roles.

Therefore, the statement that an ABR must also be a BR isFALSE.
