Free Fortinet NSEI_OTS_AR-7.6 Practice Exam with Questions & Answers | Set: 2

The correct answers are B and C . The study guide states that “You can use application control signatures to detect OT protocols” and that “Application control detects the protocols used in applications like Modbus, IEC 104, and the contents of the telecontrol messages” . It also shows that a Modbus application control profile can be enabled on a firewall policy “for OT protocol visibility in the monitor status.” This directly supports B , because application control is the feature used to identify and monitor OT protocols on FortiGate.

The guide also explains under IPS that “By default, OT signatures are excluded from the signatures lists on the GUI until you enable them on the CLI” using config ips global and set exclude-signatures none . Once enabled, FortiGate can use those OT signatures for OT-aware inspection and protection. That supports C as the second required configuration. A is related to device discovery, not protocol identification, and D is focused on exploit and vulnerability detection rather than the first-step goal of identifying OT protocols.

According to the OT Security 7.6 Architect study guide regarding the Purdue Model :

Asset Location : The study guide states that " All critical physical assets are located on the plant floor and equipped with IIoT sensors. "

Level Classification : The " plant floor " is further defined as the " control area zone, " which consists of Levels 0, 1, and 2 .

Hierarchy : The " Operations & Control " zone is identified as Level 3 and Level 3.5 .

Direct Answer : In the " Introduction " lesson ' s Knowledge Check , the specific question " In the Purdue model, at which level are IIoTs placed? " is provided with the verified answer: Below Level 3.5 .

The correct answer is D. You must configure a layer 3 switch .

The study guide explains that “Layer 2 devices can add or remove tags” but “cannot modify them.” It then states that “A layer 3 device, such as a router or FortiGate, can modify the VLAN tag before routing the packet. This allows them to route traffic between VLANs.” It also explicitly describes “Router on a Stick” as “a way to allow routing between VLANs.” Since the exhibit shows a layer-2 switch and the Engineering Workstation and PLC are placed in different VLANs, inter-VLAN communication requires layer-3 routing.

The other options do not solve this requirement. intra-switch-policy explicit/implicit applies to a software switch , where member interfaces are in the same broadcast domain and same subnet, not to routing between separate VLANs. forward domain IDs are used in transparent mode to confine broadcasts to specific broadcast domains; they do not provide inter-VLAN access. Therefore, to let the Engineering Workstation in one VLAN reach the PLC in another VLAN, you need a layer 3 routing function , which matches option D .
