Stacked charts represent a series in a single bar with multiple sections. A chart is a graphical representation of data that shows trends, patterns, or comparisons. A chart can have different types, such as column, bar, line, area, pie, etc. A chart can also have different modes, such as split-series, multi-series, stacked, etc. A stacked chart is a type of chart that shows multiple series in a single bar or area with different sections for each series

Using the export function, you can export search results as XML or JSON2. The export function allows you to save your search results in a structured format that can be used by other applications or tools2. You can use the output_mode parameter to specify whether you want to export your results as XML or JSON2. Therefore, options A and B are correct, while options C and D are incorrect because they are not formats that you can export your search results as.

In Splunk, the transaction command is used to group events that share common characteristics into a single transaction1. By default, the transaction command groups all matching events into a single transaction1.

However, you can use the maxspan option to limit the time span of the transactions1. If the time span between the first and last event in a transaction exceeds the maxspan value, the transaction command will start a new transaction1.

Therefore, if the maxspan option is not included in the search, the transaction command might produce multiple transactions instead of one if the time span between the first and last event in a transaction exceeds the default maxspan value1.

Here is an example of how you can use the maxspan option in a search:

index=main sourcetype=access_combined | transaction someuniqefield maxspan=1h

In this search, the transaction command groups events that share the same someuniqefield value into a single transaction, but only if the time span between the first and last event in the transaction does not exceed 1 hour1. If the time span exceeds 1 hour, the transaction command will start a new transaction1.

The fillnull command replaces null values in fields with a specified replacement value.

Extract: “Use fillnull to replace null field values with a string or numeric value that you specify.”

Thus, in this case, all null field values are replaced with “Unknown.”

The rex command allows you to extract fields from events using regular expressions. You can use the rex command to specify a named group that matches the port number in the event. For example:

rex "\+\+\+\+port (?\d+)"

This will create a field called port with the value 54 for the event.

The delimiter method is not suitable for this event because there is no consistent delimiter between the fields. The regular expression method is not a valid option for the Field Extractor tool. The Field Extractor tool can extract regular expressions, but it is not a method by itself.

The eval command ‘if’ function requires the following three arguments (in order): boolean expression, result if true, result if false. The eval command is a search command that allows you to create new fields or modify existing fields by performing calculations or transformations on them. The eval command can use various functions to perform different operations on fields. The ‘if’ function is one of the functions that can be used with the eval command to perform conditional evaluations on fields. The ‘if’ function takes three arguments: a boolean expression that evaluates to true or false, a result that will be returned if the boolean expression is true, and a result that will be returned if the boolean expression is false. The ‘if’ function returns one of the two results based on the evaluation of the boolean expression.
