Free Splunk SPLK-1002 Practice Exam with Questions & Answers | Set: 2

Tags are aliases or alternative names for field values in Splunk. They can make your data more understandable by using common or descriptive terms instead of cryptic or technical terms. For example, you can tag a field value such as “200” with “OK” or “success” to indicate that it is a HTTP status code for a successful request. Tags are case sensitive, meaning that “OK” and “ok” are different tags. Tags are created at search time, meaning that they are applied when you run a search on your data. Tags are searched by using the syntax tag::, where  is the name of the tag you want to search for.

A chart is a graphical representation of your search results that shows the relationship between two or more fields2. You can display a chart in stack mode by changing the Stack Mode option in the Format menu2. Stack mode allows you to stack multiple series on top of each other in a chart to show the cumulative values of each series2. Therefore, option C is correct, while options A, B and D are incorrect because they are not ways to display a chart in stack mode.

The search below groups events by two or more fields (clientip and host), creates transactions with start and end constraints (maxspan=30s and maxpause=5s), and calculates the duration of each transaction.

index=main | transaction clientip host maxspan=30s maxpause=5s

The search does the following:

It filters the events by the index main, which is a default index in Splunk that contains all data that is not sent to other indexes.

It uses the transaction command to group events into transactions based on two fields: clientip and host. The transaction command creates new events from groups of events that share the same clientip and host values.

It specifies the start and end constraints for the transactions using the maxspan and maxpause arguments. The maxspan argument sets the maximum time span between the first and last events in a transaction. The maxpause argument sets the maximum time span between any two consecutive events in a transaction. In this case, the maxspan is 30 seconds and the maxpause is 5 seconds, meaning that any transaction that has a longer time span or pause will be split into multiple transactions.

It creates some additional fields for each transaction, such as duration, eventcount, startime, etc. The duration field shows the time span between the first and last events in a transaction.

The search modes determine how Splunk processes your search and displays your results2. There are three search modes: Fast, Smart and Verbose2. The search mode that automatically returns all extracted fields in the fields sidebar is Verbose2. The Verbose mode shows all the fields that are extracted from your events, including default fields, indexed fields and search-time extractedfields2. The fields sidebar is a panel that shows the fields that are present in your search results2. Therefore, option C is correct, while options A and B are incorrect because they are not search modes that automatically return all extracted fields in the fields sidebar.

"Calculated fields can reference all types of field extractions and field aliasing, but they cannot reference lookups, event types, or tags."

The transaction command is a Splunk command that finds transactions based on events that meet various constraints .

Transactions are made up of the raw text (the _raw field) of each member, the time and date fields of the earliest member, as well as the union of all other fields of each member .

The transaction command groups events together by matching one or more fields that have the same value across the events . For example, | transaction clientip will group events that have the same value in the clientip field.
