Free Huawei H13-511_V5.5 Practice Exam with Questions & Answers | Set: 2

FusionAccess OA security architecture adoptszone-based isolation(red, yellow, green zones).

Each zone islogically and physically isolated

Each zone has itsown FusionAccess system

Data is not allowed to flow freely between zones

OptionBis false because it incorrectly states that data can be transmitted between zones. The other statements correctly reflect FusionAccess OA security and integration characteristics.

FusionAccess supports different desktop pool types, each with specific provisioning rules:

Static Pool supports both linked clone and full copy desktops → A is true.

Quick provisioning allows flexible desktop assignment strategies → B is true.

VM grouping is finalized during desktop assignment → C is true.

Dynamic Pool typically supports linked clone desktops only, because desktops are created and destroyed dynamically.

Therefore, statement D is false.

CPU virtualization is a fundamental concept in HCIA–Cloud Computing and includes multiple implementation methods.

Option A is correct. CPU virtualization is commonly categorized into full virtualization, paravirtualization, and hardware-assisted virtualization.

Option B is correct. Full virtualization allows guest operating systems to run without modification, which ensures high compatibility and portability across different platforms.

Option C is correct in the HCIA context. Paravirtualization requires modifications to the guest OS kernel, which historically limited support primarily to open-source operating systems.

Option D is false. Hardware-assisted virtualization explicitly requires CPU support, such as Intel VT-x or AMD-V. Without these features, hardware-assisted virtualization cannot function.

Therefore, the false statement is D.

In FusionCompute architecture,CNAandVRMhave clearly defined deployment models.

OptionAis false.CNA is deployed only on physical servers(compute nodes). It is responsible for interacting directly with hardware resources and cannot run inside a VM.

OptionBis true. When VRM is deployed on physical servers,active and standby VRM nodes must be installed on separate physical serversto ensure high availability.

OptionCis true. When VRM is deployed on virtual machines, the active and standby VRM VMs must be placed ondifferent hosts within the management clusterto avoid single points of failure.

OptionDis true. VRM supports deployment oneither physical servers or virtual machines, providing flexible management options.

Therefore, the correct answers areB, C, and D.

Quick provisioning using alinked clone templateis designed to rapidly deploy desktops while ensuring standardization and automation.

According to HCIA–Cloud Computing FusionAccess service provisioning procedures, the quick provision workflow includes:

Creating the VMbased on the linked clone template and snapshot.

Renaming the VMto meet enterprise naming rules.

Adding the VM to the domain, enabling centralized authentication and policy control.

Associating the VM with a user or user group, which determines desktop assignment and access permissions.

All listed operations are integral steps in the linked clone quick provisioning process. Therefore,all options are correct.

In Active Directory (AD),domainsandorganizational units (OUs)serve different purposes.

Ais true. Both domains and OUs can contain AD objects such as users, computers, and groups.

Bis true. Authentication is performed at thedomain level. Users log in to a domain, not to an OU.

Cis true.Group Policy Objects (GPOs)can be applied at both the domain level and the OU level.

Dis false. An OU can existinside a domain, but adomain cannot exist inside an OU. Domains are top-level logical boundaries.

Therefore, the correct answers areA, B, and C.

In Linux-based virtualization environments, aTAP deviceis a software-based virtual network interface that operates atLayer 2of the OSI model.

TAP devices are independently maintained by the Linux kernel and are commonly used to connect virtual machines to virtual switches or bridges. They simulate physical Ethernet interfaces, allowing VMs to send and receive Ethernet frames.

This definition aligns with HCIA–Cloud Computing networking fundamentals, so the statement isTRUE.

RAID 0

➡Multiple disks are combined to form a large-capacity storage device. This RAID level supports data striping to improve read and write speed, but does not provide data verification or redundancy backup.

RAID 1

➡Data on one disk is mirrored to another disk to provide complete redundancy backup.

RAID 5

➡Parity data is distributed on all disks in the array. Write operations can be performed on different disks at the same time.

RAID 10

➡Mirror backup is performed for each disk, and then the disks are combined to form a storage device, providing high read and write performance in addition to redundancy backup.

In HCIA–Cloud Computing (Operating System Basics), Linux network interface configuration is a foundational skill, and openEuler follows the standard Red Hat–style network configuration syntax.

To configure a static IP address, the parameter BOOTPROTO must be set to static. This tells the operating system not to request an IP address from a DHCP server and instead use the manually configured values such as IPADDR and NETMASK.

To ensure that the NIC is automatically activated when the system boots, the parameter ONBOOT must be set to yes. If ONBOOT is set to no, the interface will remain down after boot and must be manually started.

Therefore, the completed and correct configuration is:

BOOTPROTO=static

ONBOOT=yes

BOOTPROTO=static → Uses a fixed IP address

ONBOOT=yes → Enables automatic startup at system boot

This configuration exactly matches HCIA–Cloud Computing requirements for static IP configuration on openEuler.
