Free Axis Communications ANVE Practice Exam with Questions & Answers | Set: 9

AXIS Device Manager is free of charge. This tool provides comprehensive management capabilities for Axis devices without any additional licensing fees. It allows users to efficiently manage, configure, and maintain their Axis network cameras and other devices, ensuring optimal performance and security. Axis offers this tool as part of their commitment to providing user-friendly and cost-effective solutions, as detailed in their product information and support resources.

Top of Form

Bottom of Form

To identify people with 80 pixels per face in a hallway that is 2.5 meters wide, a minimum resolution of 1280x720 (720p) is needed. This resolution ensures sufficient pixel density to capture detailed facial features necessary for identification purposes. Given the width of the hallway and the required pixel density, 720p provides the necessary coverage and detail.

If the live Motion JPEG video appears pixelated without digital zoom, decreasing the image compression would be the best approach to improve the image quality. Higher compression reduces the amount of data and can result in pixelation. By lowering the compression, the image retains more data and detail, thus reducing pixelation.

People counting analytics with Axis cameras are utilized for various purposes. In retail stores, these analytics provide valuable statistics on customer foot traffic, helping with operational and marketing decisions. Enhanced service levels for public transportation benefit from people counting by monitoring passenger loads and optimizing service schedules. Crowd detection for marketing purposes leverages the analytics to understand customer behavior and preferences in different areas, which can influence marketing strategies. Axis Communications highlights these use cases in their documentation, emphasizing the analytics' role in improving operational efficiency and strategic planning.

The capability to view and record up to four different areas of the whole image of an AXIS P1346 camera is called Multi-view streaming. This feature allows multiple cropped views to be created from a single high-resolution video stream, enabling more efficient use of bandwidth and storage while focusing on specific areas of interest within the full image. For more information, refer to the Axis Communications product documentation and technical notes on Multi-view streaming capabilities.

IEEE 802.1X is a network access control protocol that provides an authentication mechanism for devices wishing to connect to a LAN or WLAN. It ensures that only approved devices are granted access to the network, thereby preventing unauthorized devices from connecting. This makes it impossible for someone to disconnect a camera and connect another device to eavesdrop on the network. Therefore, the correct answer is B. For more detailed information, refer to Axis Communications' documentation on network security features and IEEE 802.1X.

Multicast video streaming has several important characteristics:

A. Multicast can help to save bandwidth in a network because it allows the same video stream to be delivered to multiple users simultaneously, reducing the need for multiple unicast streams.

B. Multicast can typically not be used to provide video over the internet because many routers and firewalls do not support multicast traffic across the internet, which is more suited for local network environments.

D. Multicast extends the viewer capacity of a camera or an encoder from 10-20 to an unlimited number, as it does not rely on multiple individual connections to distribute the video stream.

A camera with a fixed iris is best mounted outside in a shadowed position. Fixed iris lenses do not adjust to changes in light levels, making them less suitable for environments with varying lighting conditions. By placing the camera in a shadowed position, you minimize the impact of direct sunlight and glare, which can cause overexposure and poor image quality. Therefore, the correct answer is C. For more detailed information, refer to Axis Communications' documentation on camera installation and fixed iris lenses.

When installing a network camera with PoE, the following best practices should be considered:

C. The correct PoE standards are being used. This ensures compatibility between the camera and the PoE switch or injector, preventing power issues.

E. The correct cabling standards are being used. Category 5e or higher cabling is recommended to ensure reliable power delivery and data transmission over PoE.

Following these practices helps in achieving a stable and efficient PoE camera installation.

Axis thermal cameras are designed to detect activity in both daylight and complete darkness by capturing the heat emitted by objects and people. Unlike traditional cameras that rely on visible light, thermal cameras are effective in various lighting conditions, including complete darkness, fog, smoke, and even camouflaged objects. This makes them suitable for perimeter protection and monitoring in challenging environments. [Reference: Axis Communications - Thermal Cameras]
