Hot/warm/cold/thawed bucket types are searchable. Frozen isn ' t searchable because its either deleted at that state or archived.

 [monitor::/opt/log/crashlog/Jan27crash.txt]. This stanza means that Splunk is monitoring a single local file named Jan27crash.txt in the /opt/log/crashlog/ directory1. The monitor input type is used to monitor files and directories for changes and index any new data that is added2.

https://docs.splunk.com/Documentation/Splunk/8.2.2/Admin/Inputsconf

-Scroll down to source = < string >

*Default: the input file path

The outputs.conf file defines how forwarders send data to receivers1. You can specify some output configurations at installation time (Windows universal forwarders only) or the CLI, but most advanced configuration settings require that you edit outputs.conf1.

The [tcpout:…] stanza specifies a group of forwarding targets that receive data over TCP2. You can define multiple groups with different names and settings2.

The server setting lists one or more receiving hosts for the group, separated by commas2. If you specify multiple hosts, the forwarder load balances the data across them2.

Therefore, option A is correct, because the forwarder will send data to both inputsl.mysplunkhfs.corp:9997 and inputs2.mysplunkhfs.corp:9997, even if 145.188.183.184:9097 is unreachable.

The correct answer is C. MonitorNoHandle.

MonitorNoHandle is a type of input stanza that allows a Splunk forwarder to read files on Windows systems as Windows writes to them. It does this by using a kernel-mode filter driver to capture raw data as it gets written to the file1. This input stanza is useful for files that get locked open for writing, such as the Windows DNS server log file2.

The other options are incorrect because:

A. Tail Reader is not a valid input stanza in Splunk. It is a component of the Tailing Processor, which is responsible for monitoring files and directories for new data3.

B. Upload is a type of input stanza that allows Splunk to index a single file from a local or network file system. It is not suitable for files that are constantly being updated, as it only indexes the file once and does not monitor it for changes4.

D. Monitor is a type of input stanza that allows Splunk to monitor files and directories for new data. However, it may not work for files that Windows prevents Splunk from reading while they are open. In such cases, MonitorNoHandle is a better option2.

A Splunk forwarder is a lightweight agent that can forward data to a Splunk deployment. There are two types of forwarders: universal and heavy. A universal forwarder can only forward data, while a heavy forwarder can also perform parsing, filtering, routing, and aggregation on the data before forwarding it5.

An input stanza is a section in the inputs.conf configuration file that defines the settings for a specific type of input, such as files, directories, network ports, scripts, or Windows event logs. An input stanza starts with a square bracket, followed by the input type and the input path or name. For example, [monitor:///var/log] is an input stanza for monitoring the /var/log directory.

" The forwarder/indexer relationship can be considered platform agnostic (within the sphere of supported platforms) because they exchange their data handshake (and the data, if you wish) over TCP.

In Splunk Enterprise and Splunk Universal Forwarder, data inputs are configured using stanzas in inputs.conf . Each stanza defines a listener for a particular input type (for example, TCP or UDP) and a specific port.

Splunk documentation states that a single TCP input stanza can receive data from multiple remote hosts sending to the same TCP port, and similarly, a single UDP input stanza can receive data from multiple devices sending to the same UDP port. Therefore, the number of sending devices does not determine the number of stanzas required; rather, the input protocol and port type do.

In this case:

All three TCP devices can send data to one TCP port (one stanza).

All four UDP devices can send data to one UDP port (one stanza).

Thus, the minimum number of input stanzas required is two — one for TCP and one for UDP.

Example configuration (inputs.conf):

# TCP input for three switches sending via TCP

[tcp://9997]

sourcetype = switch_logs

# UDP input for four switches sending via UDP

[udp://514]

sourcetype = switch_logs

This configuration ensures all seven devices’ logs are collected without creating individual stanzas for each device.

Reference (Splunk Documentation):

Splunk® Enterprise Admin Manual → Configure Data Inputs → “Listen for network data”

inputs.conf.spec and example → “You can configure a single TCP or UDP input to receive data from multiple remote hosts.”

Splunk Universal Forwarder Manual → Configure Forwarding Inputs → “Universal Forwarders can listen on a single TCP or UDP port for multiple remote data sources.”
