Free ServiceNow CIS-Discovery Practice Exam with Questions & Answers | Set: 2

The Debug Identification Section in Debug Mode allows you to specify the identification attributes of a CI that you want to debug. These attributes are used to find the CI in the CMDB and run the pattern on it. The identification attributes vary depending on the CI class, but for infrastructure patterns, the common ones are IP and Host Name. These attributes are also used by the horizontal discovery to identify CIs. AWS Endpoint and PID are not valid identification attributes for infrastructure patterns.

References: The explanation is based on the following sources:

• Activate pattern Debug mode: This document explains how to activate the Debug mode and use the Debug Identification Section to debug a pattern.
• ServiceNow Exam CIS-Discovery Topic 6 Question 9 Discussion: This discussion provides a similar question and answer about the Debug Identification Section in Debug Mode.

A Functionality Definition is a configuration record that defines what protocols to detect from within a Behavior. A Behavior is a set of Functionality Definitions that Discovery uses to identify and explore a device or application. A Functionality Definition specifies the order, type, and parameters of the probes that Discovery launches to gather information about a device or application12.

References:

• Functionality Definition
• Behavior

In ServiceNow Discovery, a horizontal discovery pattern refers to the logical set of steps that the Discovery process executes to find CI information across the network. Each step in a horizontal discovery pattern performs specific operations such as running probes, executing commands, or querying databases to gather information about the configuration items (CIs). It's about expanding the breadth of discovery across devices and applications, rather than going in-depth into a specific CI's details, which would be vertical discovery. Classifiers, credential depots, and port scanning tools are part of the discovery process but do not describe the horizontal discovery pattern itself.

ServiceNow Discovery can be extended in three main ways: Classifiers, Probes & Sensors, and Discovery Patterns. Classifiers are used to identify the type of device or application that is being discovered, based on the information returned by a probe. Probes are commands or scripts that are executed on the target device or application to collect data. Sensors are scripts that process the data collected by probes and create or update configuration items (CIs) in the CMDB. Discovery Patterns are graphical representations of the discovery process that can be customized or created to discover specific types of devices or applications, using classifiers, probes, and sensors as building blocks.

References:

• Discovery overview - Product Documentation: Vancouver - Now Support Portal
• Create a Discovery CI classification - Product Documentation: Vancouver - Now Support Portal
• Discovery probes and sensors - Product Documentation: Vancouver - Now Support Portal
• Discovery patterns - Product Documentation: Vancouver - Now Support Portal

The deletion strategy ‘Mark as absent’ means that when a related CI that was previously discovered by a pattern is no longer found, the install_status attribute of that CI is set to Absent. This indicates that the CI is missing or removed from the network. The main CI (in this case, the Linux Server CI) is not affected by the deletion strategy of the related CI (in this case, the Disk CI)12.

References1: Set a deletion strategy - Product Documentation: San Diego - ServiceNow2: Network adapter status setting to “Absent” in EMC … - ServiceNow …

The Put file operation allows the transfer of a file from the MID Server to a target1. This operation can be used to copy files from the MID Server to a target device, such as configuration files, scripts, or binaries2. The Put file operation requires the file path on the MID Server and the file path on the target as inputs2.

References:

• 1: Put file
• 2: Define discovery steps

 According to the ServiceNow Discovery documentation, the base system CI Identifiers for Windows Server class are name and serial_number. These are the attributes that Discovery uses to uniquely identify a Windows Server CI. If both attributes match an existing CI, Discovery updates that CI. If only one attribute matches, Discovery creates a new CI. If neither attribute matches, Discovery also creates a new CI. In this scenario, the serial_number is the same for both Windows Servers, but the name is different. Therefore, Discovery will create two separate CIs, one with WindowsSN1 as the name and one with WindowsSN2 as the name.

References:

• Create a Discovery CI classification - Product Documentation: Tokyo - Now Support Portal
• Identification rules - Product Documentation: Tokyo - Now Support Portal
• ServiceNow IRE: Identification Rules Explained — Cookdown

The vCenter Event Collector is a MID Server extension that listens for vCenter-related events and updates the CMDB accordingly. The event collector allows the CMDB to be updated with changes to virtual machines (VMs), in addition to the updates detected by Discovery1.

References:

• 3: Product Documentation | ServiceNow

Step 25 uses a shared library called Windows - Storage, which is a reusable component that can be invoked by multiple patterns to discover the storage information of Windows servers. A shared library is a collection of steps that can be referenced by a pattern name and can accept input parameters and return output values. Shared libraries help to avoid duplication of code and simplify the maintenance of patterns.

References:

• Pattern Designer | Shared libraries
• Windows - Storage shared library
