In Panorama, zones defined in a template must be linked to a device group for visibility in policy creation. Adding the template as a reference template in the device group (Option B) ensures its zones are available in the policy editor’s drop-down list.

Option A (master device) affects User-ID, not zones. Option C (add firewall) is a prerequisite, not a fix. Option D (share objects) is unrelated to zones. Documentation specifies reference templates for this issue.

https://www.paloaltonetworks.com/content/dam/pan/en_US/assets/pdf/datasheets/education/pcnse-study-guide.pdf page 83

When troubleshooting Palo Alto Networks services, such as dynamic updates, verifying the status of service routes is critical. Service routes determine how the firewall communicates with external services (e.g., Palo Alto Networks update servers, WildFire, DNS, etc.) from the Management Plane or data plane interfaces.

Why "debug dataplane internal vif route 250" is Correct

Purpose of the Command:

This command allows administrators to view the service routes configured on the firewall and verify if they are installed correctly and actively working.

The number 250 specifically refers to service routes in the Management Plane.

Output:

The command displays detailed information about service routes, including routing decisions, source interfaces, and next-hop IPs.

Helps identify issues such as:

Incorrect interface configuration.

Invalid next-hop IPs.

Missing routes for specific services.

Analysis of Other Options

debug dataplane internal vif route 255

Incorrect:

The number 255 does not correspond to service routes but is used for internal route debugging unrelated to management plane service routes.

show routing route type management

Incorrect:

This command does not exist in PAN-OS CLI. It might be a misrepresentation of another command.

debug dataplane internal vif route 250

Correct:

As explained above, this is the correct command for verifying service routes in the Management Plane.

show routing route type service-route

Incorrect:

This is not a valid PAN-OS CLI command.

PAN-OS Documentation Reference

Service Routes in PAN-OS 11.0:

The configuration and verification of service routes are covered under the Device > Setup > Services section of the GUI.

For CLI, the debug dataplane internal vif route 250 command is specifically used for troubleshooting service routes in the Management Plane.

For more details, refer to:

PAN-OS 11.0 CLI Guide: Covers debugging tools and service route verification.

PCNSA Study Guide: Domain 1 includes service route configurations and their importance in maintaining connectivity for management services.

Device Group Hierarchy

Shared

DATACENTER_DG

DC_FW_DG

REGIONAL_DG

OFFICE_FW_DG

FW-1_DG

Analysis

Considerations:

FW-1 is assigned to the FW-1_DG device group.

FW-2 is assigned to the OFFICE_FW_DG device group.

There are no objects configured in REGIONAL_DG and OFFICE_FW_DG device groups.

The address object Server-1 appears in multiple device groups with different IP addresses. The device groups have a hierarchy, which means objects can be inherited from parent groups unless overridden in the child group.

FW-1_DG:

Server-1 has IP 4.4.4.4, which will be pushed to FW-1 because it is in the FW-1_DG device group.

OFFICE_FW_DG (for FW-2):

Since there are no objects in OFFICE_FW_DG and REGIONAL_DG, FW-2 will inherit from Shared.

In the Shared group, Server-1 has IP 1.1.1.1.

https://docs.paloaltonetworks.com/pan-os/11-1/pan-os-admin/authentication/configure-multi-factor-authentication

In Palo Alto Networks firewalls, when multiple static routes exist for the same destination, the firewall uses the administrative distance (AD) to determine route priority. The AD is a metric that indicates the trustworthiness of a route, with lower values indicating higher priority. For static routes, the default AD is 10, but this can be manually adjusted. The route with the lowest AD is preferred and added to the routing table. If AD values are equal, the firewall then considers the metric (default 10), but AD is the primary differentiator.

Option A (first route installed) is incorrect, as route installation order does not determine priority. Option C (Bidirectional Forwarding Detection) is a protocol for detecting link failures, not route priority. Option D (highest AD) is the opposite of the correct behavior. This aligns with standard routing principles and Palo Alto’s implementation.
